Description

1. Contact: Tin-plated copper

2. Waterproof: IP67

3. Housing material: 100% GE PPO.

4. Rated Voltage: TUV 1500V DC/UL 1000V DC

5. pin Dimension: 4.0mm, solid terminal

6. Rated current:30A-60A

7. Flame Class:UL94V-0

8. Resistance: ≤5mΩ

9. Pollution degree:2

10.Protection Class: Class II

11.Temperature Range：-40°C to 90°C

12.Wire Size Range：2.5mm²~6mm²

13.Insertion Force/Withdrawal Force：≤50 Newton/ ≥50 Newton

14.TUV standard, UV resistant
